Lithium-iron-phosphate (LiFePO4 or LFP) is the safest of the mainstream li-ion battery types. The nominal
voltage of a LFP cell is 3,2V (lead-acid: 2V/cell). A 12,8V LFP battery therefore consists of 4 cells connected in
series
A LFP battery does not need to be fully charged. Service life even slightly improves in case of partial charge
instead of a full charge. This is a major advantage of LFP compared to lead-acid.
Our LFP batteries have integrated cell balancing and cell monitoring. Up to 5 batteries can be paralleled and up to four 12V batteries . The cell balancing/monitoring cables can be daisy-chained and must be connected to a Battery Management System (BMS).
Nominal voltage : 12,8V
Nominal capacity @ 25°C* : 200Ah
CYCLE LIFE (capacity ≥ 80% of nominal) : 50% DoD – 5000 cycles
Maximum continuous discharge current : 400A
Recommended continuous discharge current : ≤200A
End of discharge voltage : 11,2V
Maximum charge current : 400A
Recommended charge current : ≤100A
Power Connection M8 threaded inserts
