Li-ion system with internal charger
Lightweight , Space-saving , high-performance battery
Maintenance-free.
Capacity : 20Ah ; 256Wh
Battery type : Lithium-ion (LiFePO4) @ 12.8V
Output 1 : Continuous output current: high capacity “mover” ( 150A )
Maximum charging current : 15A
Safety features : Overload / short-circuiting / temperature / excessive discharge
Recommended charging voltage : 14V (no protection) – screw clamps 16mm²
Output 2 : Continuous output current : on-board power network “domestic” ( 30A )
Maximum charging current : 10A
Safety features : Overload / short-circuiting / temperature / excessive discharge
Recommended charging voltage : 14V (no protection) – screw clamps 6mm²
Input 1: “car/solar” @ 11 V < Vin < 25 V , max .7A
Input 2: “adapter” @ max 15V / 3A
Battery charging: 0°C to 40°C ; Battery discharge: -20°C to +40°C ; Storage: -20°C to +40°C
Communication with a smartphone (VE.Direct Bluetooth Smart-dongle required)
Safety Standards : EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1
